Date: 4 December 2018
Sound parameters of the glass were confirmed by mandatory certificates recognised on the European and North American markets.
| No. | Structure [mm] | Rw [dB] | C [dB] | Ctr [dB] |
|---|---|---|---|---|
| 1 | 8,8T (VSG 44.2T) Acoustic/12Ar/6/12Ar/4T | 41 | -1 | -5 |
| 2 | 6,4T (VSG 33.1T) Acoustic/12Ar/4/12Ar/6,4T (VSG 33.1T) Acoustic | 43 | -2 | -6 |
| 3 | 8,8T (VSG 44.2T) Acoustic/16Ar/8,8T (VSG 44.2T) Acoustic | 45 | -3 | -8 |
| 4 | 6,4T (VSG 33.1T)/12Ar/4/12Ar/26,6 Pyrobel 25 | 46 | -2 | -6 |
| 5 | 8,4T (VSG 44.1T) Acoustic/12Ar/4/12Ar/8,4T (VSG 44.1T) Acoustic | 47 | -2 | -6 |
| 6 | 8,4T (VSG 44.1T) Acoustic/12Ar/6/12Ar/8,4T (VSG 44.1T) Acoustic | 47 | -2 | -6 |
| 7 | 8,8T (VSG 44.2T) Acoustic/12Ar/6/12Ar/8,4T (VSG 44.1T) Acoustic | 47 | -2 | -6 |
| 8 | 8,8T (VSG 44.2T) Acoustic/12Ar/6/12Ar/8,8T (VSG 44.2T) Acoustic | 47 | -2 | -6 |
| 9 | 9,5T (VSG 44.4T)/12Ar/6/12Ar/8,8T (VSG 44.2T) Acoustic | 47 | -2 | -6 |
| 10 | 9,5T (VSG 44.4T)/12Ar/8/12Ar/8,8T (VSG 44.2T) Acoustic | 47 | -2 | -6 |
| 11 | 8,8T (VSG 44.2T) Acoustic/12Ar/8/12Ar/8,4T (VSG 44.1T) Acoustic | 48 | -2 | -7 |
| 12 | 8,8T (VSG 44.2T) Acoustic/12Ar/8/12Ar/8,8T (VSG 44.2T) Acoustic | 48 | -2 | -7 |
| 13 | 10,8T (VSG 55.2T) Acoustic/12Ar/6/12Ar/8,8T (VSG 44.2T) Acoustic | 48 | -2 | -6 |
T – Thermofloat (glass with thermal protection coating)
Ar – noble gas – Argon
VSG – laminated safety glass
Pyrobel 25 – fire resistant, indoor glass
Press Glass can now offer to its Customers as many as 133 different acoustic glazed units within the range of 31- 52 dB. "The range of acoustic glazed units from Press Glass has been gradually extended by adding new items. We know how difficult choosing the right acoustic glazed unit can be.
That is why we encourage our Customers to use two dedicated free tools: Soundproof Glass Configurator and Noise Damping Simulator, which are available on our website: www.pressglass.com and in PRESS GLASS MOBILE application (for iOS and Android).
Both tools contain a full list of acoustic glazed units from our portfolio. The configurator enables quick checking and comparison of sound parameters of acoustic glazed units. The simulator can be used to quickly compare the acoustic results for all acoustic glazed units. Both tools will certainly facilitate choosing the preferred acoustic glazed units", says Gerard Plaze from Press Glass promotion department.
Acoustic glass units - more https://www.pressglass.com/market-offer/glazed-units/acoustic-glazed-units/
Soundproof glass configurator – https://tools.pressglass.com/soundproof-glass-configurator/en
Noise damping simulator - https://nds.pressglass.com/?lang=en
